Key Specification
Model
D-160
Power supply
110-120V/60Hz
220-240V/50-60Hz
Motor type
160W Carbon brush motor
Speed range
8000rpm – 30000rpm
Max. circum. speed
6.3 – 14msec
Speed control dial knob
6 stage
Working volume
0.1-50mL (Dispersing shaft DS-160/5)
1-250mL (Dispersing shaft DS-160/10)
Max viscosity
5,000m Pas
Material of Dispersing Shaft
SS316L Stainless steel, PTFE
Weight
0.6 kg
Dimension
46mm x 55mm x 230mm
Noise
72 bB(A)
IP protection class
IP20
Permissible ambient temperature
0~40°C
Permissible relative humidity
85%RH
Overhead Stirrer
Product No
Product Name
Description
18900113
DS-160/5
Dispersing shaft 5mm, for solid/liquid media and volumes from 0.1-50ml
18900114
DS-160/10
Dispersing shaft 10mm, for solid/liquid media and volumes from 1- 250ml
Description
Model
D-160
Power supply
110-120V/60Hz
220-240V/50-60Hz
Motor type
160W Carbon brush motor
Speed range
8000rpm – 30000rpm
Max. circum. speed
6.3 – 14msec
Speed control dial knob
6 stage
Working volume
0.1-50mL (Dispersing shaft DS-160/5)
1-250mL (Dispersing shaft DS-160/10)
Max viscosity
5,000m Pas
Material of Dispersing Shaft
SS316L Stainless steel, PTFE
Weight
0.6 kg
Dimension
46mm x 55mm x 230mm
Noise
72 bB(A)
IP protection class
IP20
Permissible ambient temperature
0~40°C
Permissible relative humidity
85%RH
Overhead Stirrer
Product No
Product Name
Description
18900113
DS-160/5
Dispersing shaft 5mm, for solid/liquid media and volumes from 0.1-50ml
18900114
DS-160/10
Dispersing shaft 10mm, for solid/liquid media and volumes from 1- 250ml
